Wireless Actuator MCF-LW13IO

Wireless Actuator MCF-LW13IO

The MCF-LW13IO is an efficient LoRaWAN® wireless actuator, ideal for a variety of applications such as industrial process control, home automation, water treatment, and agriculture irrigation. It transmits input status and controls outputs through the LoRaWAN® network.

Specifications

  • CPU: Cortex M0+
  • Memory: 32KB EEProm, 64KB Flash
  • Security: AES 128-bit encryption
  • Connectivity: Class C LoRaWAN® stack EU868, AS923, AU915, US915
  • Inputs: 1 opto-isolated input (230Vac)
  • Outputs: 1 relay output with COM, NO, NC contacts (230Vac, 8A)
  • NFC: For IoT node setup and firmware upgrade
  • Power Supply: From AC line
  • Operating Temperature Range: -10 to +70°C
  • Dimensions: 58x44x25mm

Summary

The MCF-LW13IO LoRaWAN® Wireless Actuator is a compact and versatile device, providing effective control for a variety of applications, ensuring reliable connectivity and easy integration into existing LoRaWAN® networks.
Download specs
